FEATURES
- One channel 500W high efficiency Class-D amplifier
- Effective ventilation using forced air cooling fan
- Automatic protection
- Fault detection
- CE compliant
Input/Output
X-DA1500-B supports both balanced and unbalanced audio inputs. To receive unbalanced audio inputs, simply connect the ground port with the negative input port to the rear panel. X-DA1500-B can receive audio signal from X-DCS2000/EN via Ethernet through the RJ45 standard port.
Fault Detection
X-DA1500-B can self-protect from overheat, overcurrent, overvoltage and undervoltage. For example, when the internal temperature reaches its critical limit, the overheat protection circuit will shut down the power amplification module and activate the protection indicator light on the front panel.
X-DA1500-B can detect power supply errors automatically during operation. The built-in fuse will provide overcurrent protection to the main power supply. When a short circuit is detected in the main power circuit, the power will be automatically shut down. The backup power will then be enabled to replace the main one. When a fault or self-protection or self-testing happens, its audio input port will short circuit and a fault signal will be sent to the control unit in the network.
Safety
The device adopts a lightweight design. The front panel is made of UL94V-0 fire proof ABS material, protecting the machine
under extreme conditions. A cooling fan is equipped for heat exhaustion so that the machine can maintain high working efficiency.
Volume Control
When HN-D32N Noise Detector is installed, X-DA1500-B can adjust volume according to the ambient noise automatically to ensure high sound intelligibility. HN-D32N
